Double Top/Bottom Screener V1

//version=6
indicator("Double Top/Bottom Screener", overlay=true, max_lines_count=500)

// Inputs
leftBars = input.int(5, "Left Bars")
rightBars = input.int(5, "Right Bars")
tolerance = input.float(0.02, "Max Difference (e.g., 0.02 for 2 cents)", step=0.01)
atrLength = input.int(14, "ATR Length for Normalized Distance", minval=1)
requiredPeaks = input.int(3, "Required Identical Peaks", minval=2, maxval=5)

// Declarations of persistent variables and arrays
var array<float> resistanceLevels = array.new<float>(0)
var array<int> resistanceCounts = array.new<int>(0)
var array<float> supportLevels = array.new<float>(0)
var array<int> supportCounts = array.new<int>(0)
var array<line> resLines = array.new<line>(0)
var array<line> supLines = array.new<line>(0)
var bool hasDoubleTop = false
var bool hasDoubleBottom = false
var float doubleTopLevel = na
var float doubleBottomLevel = na
var int todayStart = na
var bool isNewDay = false

// Step 1: Identify Swing Highs/Lows
swingHigh = ta.pivothigh(high, leftBars, rightBars)
swingLow = ta.pivotlow(low, leftBars, rightBars)

// Today's premarket start (04:00 AM ET)
if dayofmonth != dayofmonth[1]
todayStart := timestamp(syminfo.timezone, year, month, dayofmonth, 4, 0, 0)
isNewDay := true
else
isNewDay := false

// Clear arrays and reset flags only once at premarket start
if isNewDay and time >= todayStart
array.clear(resistanceLevels)
array.clear(supportLevels)
array.clear(resistanceCounts)
array.clear(supportCounts)
array.clear(resLines)
array.clear(supLines)
hasDoubleTop := false
hasDoubleBottom := false
doubleTopLevel := na
doubleBottomLevel := na

// Add new swings and check for identical peaks
if not na(swingHigh) and time >= todayStart
bool isEqualHigh = false
int peakIndex = -1
float prevLevel = na
if array.size(resistanceLevels) > 0
for i = 0 to array.size(resistanceLevels) - 1
prevLevel := array.get(resistanceLevels, i)
if math.abs(swingHigh - prevLevel) <= tolerance
isEqualHigh := true
peakIndex := i
break
if isEqualHigh and peakIndex >= 0
array.set(resistanceCounts, peakIndex, array.get(resistanceCounts, peakIndex) + 1)
if array.get(resistanceCounts, peakIndex) == requiredPeaks
hasDoubleTop := true
doubleTopLevel := prevLevel
else
array.push(resistanceLevels, swingHigh)
array.push(resistanceCounts, 1)
line newResLine = line.new(bar_index - rightBars, swingHigh, bar_index, swingHigh, color=color.red, width=2, extend=extend.right)
array.push(resLines, newResLine)

if not na(swingLow) and time >= todayStart
bool isEqualLow = false
int peakIndex = -1
float prevLevel = na
if array.size(supportLevels) > 0
for i = 0 to array.size(supportLevels) - 1
prevLevel := array.get(supportLevels, i)
if math.abs(swingLow - prevLevel) <= tolerance
isEqualLow := true
peakIndex := i
break
if isEqualLow and peakIndex >= 0
array.set(supportCounts, peakIndex, array.get(supportCounts, peakIndex) + 1)
if array.get(supportCounts, peakIndex) == requiredPeaks
hasDoubleBottom := true
doubleBottomLevel := prevLevel
else
array.push(supportLevels, swingLow)
array.push(supportCounts, 1)
line newSupLine = line.new(bar_index - rightBars, swingLow, bar_index, swingLow, color=color.green, width=2, extend=extend.right)
array.push(supLines, newSupLine)

// Monitor and remove broken levels/lines; reset pattern if the equal level breaks
if array.size(resistanceLevels) > 0
for i = array.size(resistanceLevels) - 1 to 0
float level = array.get(resistanceLevels, i)
if close > level
line.delete(array.get(resLines, i))
array.remove(resLines, i)
array.remove(resistanceLevels, i)
array.remove(resistanceCounts, i)
if level == doubleTopLevel
hasDoubleTop := false
doubleTopLevel := na

if array.size(supportLevels) > 0
for i = array.size(supportLevels) - 1 to 0
float level = array.get(supportLevels, i)
if close < level
line.delete(array.get(supLines, i))
array.remove(supLines, i)
array.remove(supportLevels, i)
array.remove(supportCounts, i)
if level == doubleBottomLevel
hasDoubleBottom := false
doubleBottomLevel := na

// Limit arrays (after removals)
if array.size(resistanceLevels) > 10
line oldLine = array.shift(resLines)
line.delete(oldLine)
array.shift(resistanceLevels)
array.shift(resistanceCounts)
if array.size(supportLevels) > 10
line oldLine = array.shift(supLines)
line.delete(oldLine)
array.shift(supportLevels)
array.shift(supportCounts)

// Pattern Signal: 1 only if the exact required number of peaks is met
patternSignal = (hasDoubleTop or hasDoubleBottom) and (array.size(resistanceCounts) > 0 and array.get(resistanceCounts, array.size(resistanceCounts) - 1) == requiredPeaks or array.size(supportCounts) > 0 and array.get(supportCounts, array.size(supportCounts) - 1) == requiredPeaks) ? 1 : 0

// New: Nearest Double Level Price
var float nearestDoubleLevel = na
if hasDoubleTop and not na(doubleTopLevel)
nearestDoubleLevel := doubleTopLevel
if hasDoubleBottom and not na(doubleBottomLevel)
nearestDoubleLevel := na(nearestDoubleLevel) ? doubleBottomLevel : (math.abs(close - doubleBottomLevel) < math.abs(close - nearestDoubleLevel) ? doubleBottomLevel : nearestDoubleLevel)

// New: Distance to Nearest Level (using ATR for normalization)
var float atr = ta.atr(atrLength)
var float distanceNormalizedATR = na
if not na(nearestDoubleLevel) and not na(atr) and atr > 0
distanceNormalizedATR := math.abs(close - nearestDoubleLevel) / atr

// Optional Bounce Signal (for reference)
bounceSignal = 0
if array.size(resistanceLevels) > 0
for i = 0 to array.size(resistanceLevels) - 1
float level = array.get(resistanceLevels, i)
if low <= level and high >= level and close < level
bounceSignal := 1
if array.size(supportLevels) > 0
for i = 0 to array.size(supportLevels) - 1
float level = array.get(supportLevels, i)
if high >= level and low <= level and close > level
bounceSignal := 1

// Outputs
plot(patternSignal, title="Pattern Signal", color=patternSignal == 1 ? color.purple : na, style=plot.style_circles)
plot(bounceSignal, title="Bounce Signal", color=bounceSignal == 1 ? color.yellow : na, style=plot.style_circles)
plot(nearestDoubleLevel, title="Nearest Double Level Price", color=color.orange)
plot(distanceNormalizedATR, title="Normalized Distance (ATR)", color=color.green)

bgcolor(patternSignal == 1 ? color.new(color.purple, 80) : na)

if patternSignal == 1 and barstate.isconfirmed
alert("Double Pattern detected on " + syminfo.ticker + " at " + str.tostring(close), alert.freq_once_per_bar_close)

if barstate.islast
var table infoTable = table.new(position.top_right, 1, 4, bgcolor=color.new(color.black, 50))
table.cell(infoTable, 0, 0, "Pattern: " + str.tostring(patternSignal), bgcolor=patternSignal == 1 ? color.purple : color.gray)
table.cell(infoTable, 0, 1, "Bounce: " + str.tostring(bounceSignal), bgcolor=bounceSignal == 1 ? color.yellow : color.gray)
table.cell(infoTable, 0, 2, "Level: " + str.tostring(nearestDoubleLevel, "#.##"), bgcolor=color.orange)
table.cell(infoTable, 0, 3, "ATR Dist: " + str.tostring(distanceNormalizedATR, "#.##"), bgcolor=color.green)
